Datalogic TL46-W-815 High-Speed Contrast Sensor | RGB LED | 10 mm Detection | Industrial-Grade IP67

Boost precision and speed in your industrial automation systems with the Datalogic TL46-W-815 Contrast Sensor. Engineered for high-speed detection and robust performance, this sensor features multiple switching frequencies, RGB LED light emission, and flexible output options for diverse application needs.

🔍 Key Specifications:

• Model No.: TL46-W-815

• Brand: Datalogic

• Sensor Type: Contrast Sensor

• Sensing Method: Optical (Contrast Detection)

• Detection Distance: 10 mm (adjustable with lens)

• Sensing Distance: 8 mm

• Switching Output: PNP

• Light Source: RGB LED / White LED / Red LED

• Switching Frequency:

  • 10 kHz (TL46-WE Color Mode)

  • 15–70 kHz (model-dependent, including TL46-WJ & WH...PZ)

• Jitter (Detection Precision): As low as <3 µs (model-specific)

• Setting Interface: Push Buttons & Trimmer (Incremental Encoder)

• Power Supply: 10–30 V DC

• Output Options:

  • PNP, NPN, Relay, Analog (0–5V)

  • IO- v1.1.2 (for smart sensor integration)

• Connection Type: Cable, Connector, or Pig-tail

• Housing Material: Durable Aluminium

• Protection Rating: IP67

• Dimensions: 31 x 81 x 58 mm

• Weight: 75 g

• Operating Temperature Range: -40°C to +125°C

⚙️ Lens Compatibility & Detection Range:

• 9 ±3 mm (Standard)

• 18 mm (Lens No.18 glass)

• 22 mm (Lens No.22 glass)

• 28 mm (Lens No.28 glass)

• 40 mm (Lens No.40 glass)

✅ Key Features:

• Extremely High Switching Frequencies – Up to 70 kHz for ultra-fast response.

• Low Jitter – High precision with <3 µs jitter in top-tier models.

• Smart Sensor Integration – Supports IO- v1.1.2 with double-channel I/O.

• Multiple Output Options – PNP, NPN, Analog, and Relay configurations available.

• Customizable Detection Range – Easily adjust focus distance using optional lenses.

• Durable Build – Aluminium housing with IP67 protection for harsh industrial conditions.

🏭 Ideal Applications:

• Packaging Lines

• Print Mark Detection

• Conveyor Systems

• Material Sorting

• High-Speed Labeling and Product Tracking

Choose the Datalogic TL46-W-815 contrast sensor for precision, durability, and adaptability in fast-paced industrial environments.
