SNAP-AITM-4I Thermocouple Input Module | Industrial Temperature Measurement | krishna-machinery-tools-kmt
Model Name/Number SNAP-AITM-4I Supplier OPTO-22 Unit of Measure Per Each Maximum Operating Common Mode Voltage 250 V Isolation: Optica 4000V OPTO 22 SNAP-AITM-4i Thermocouple or mV Input Module, SNAP-AITM-4i 4-Ch Isolated Type B, C, D, E, G, J, K, N, R, S, or T Thermocouple or +/-150, +/-75, +/-50, or +/-25 mV Analog Input Module Specification/Additional Details Usage/Application : SNAP PAC System Model Name/Number : SNAP-AITM-4i Number of Channels : 4 Rated Voltage : 5 VDC (+/-0.15) at 150 mA Product Type : Thermocouple Input Module Input Current : 150 mA A Input Range : -150 mV to +150 mVDC, -75 mV to +75 mVDC, -50 mV to +50 mVDC, -25 mV to +25 mVDC Input Filtering : -3 dB @ 5 Hz Data Freshness : mV input: 75 ms/Thermocouple input: 140 ms DC Common Mode Rejection : >-120 dB AC Common Mode Rejection : >-120 dB @ 60 Hz Maximum Survivable Input : +-15 volts Maximum Operating Common Mode Voltage : 250 V Isolation : Channel to Channel : 250 V continuous (1500 V transient)
