SI5010 IFM Flow Monitor | Industrial Flow Monitoring | krishna-machinery-tools-kmt

Number of inputs and outputs Number of digital outputs: 1 Process connection threaded connection M18 x 1,5 internal thread Application Media Liquids; Gases Medium temperature[°C] -25...80 Pressure rating 300 bar 30 MPa MAWP for applications according to CRN[bar] 208 Liquids Medium temperature[°C] -25...80 Gases Medium temperature[°C] -25...80 Electrical data Operating voltage[V] 18...36 DC Current consumption[mA] < 60 Protection class III Reverse polarity protection yes Power-on delay time[s] 10 Inputs / outputs Number of inputs and outputs Number of digital outputs: 1 Outputs Total number of outputs 1 Output signal switching signal; IO-; (configurable) Electrical design PNP Number of digital outputs 1 Output function normally open / normally closed; (parameterisable) Max. voltage drop switching output DC[V] 2.5 Permanent current rating of switching output DC[mA] 250 Short-circuit protection yes Type of short-circuit protection pulsed Overload protection yes Measuring/setting range Probe length L[mm] 45 Liquids Setting range[cm/s] 3...300 Greatest sensitivity[cm/s] 3...100 Gases Setting range[cm/s] 200...3000 Greatest sensitivity[cm/s] 200...800 Accuracy / deviations Repeatability[cm/s] 1...5 Note on repeatability for water 5...100 cm/s; 25 °C Factory setting Temperature drift[cm/s x 1/K] 0.1; (for water 5...100 cm/s; 10...70 °C) Temperature gradient[K/min] 300 Switch point accuracy[cm/s] ± 2...± 10; (for water 5...100 cm/s; 25 °C; Factory setting) Hysteresis[cm/s] 2...5; (for water 5...100 cm/s; 25 °C; Factory setting) Response times Liquids Response time[s] 1...10 Gases Response time[s] 1...10 Software / programming Adjustment of the switch point pushbutton Interfaces Communication interface IO- Transmission type COM2 (38,4 kBaud) IO- revision 1.1 SDCI standard IEC 61131-9 Profiles Smart Sensor - SSP 0 Generic Profiled Sensor Function Device identification Function Process data variable SIO mode yes Required master port type A Process data analogue 2 Process data binary 2 Min. process cycle time[ms] 3 Supported DeviceIDs Type of operation DeviceID default 54 Operating conditions Ambient temperature[°C] -25...80 Storage temperature[°C] -25...100 Protection IP 65; IP 67 Tests / approvals EMC DIN EN 61000-6-2 DIN EN 61000-6-3 Shock resistance DIN IEC 60068-2-27 50 g (11 ms) Vibration resistance DIN EN 60068-2-6 20 g (55...2000 Hz) MTTF[years] 298 Mechanical data Weight[g] 248.5 Housing cylindrical Dimensions[mm] Ø 50 / L = 113 Materials stainless steel (316L/1.4404); stainless steel (304/1.4301); PC; PBT-GF20; EPDM/X Materials (wetted parts) stainless steel (316L/1.4404); O-ring: FKM 80 Shore A Process connection threaded connection M18 x 1,5 internal thread Probe diameter[mm] 8.2 Installation length EL[mm] 45 Displays / operating elements Display function 10 x LED, three-colour Remarks Pack quantity 1 pcs. Electrical connection Connection Connector: 1 x M12; coding: A
