Datalogic SG4-RDB2 Area Sensor – Type 4 Safety Light Curtain with 2m Detection Range

Ensure optimal machine safety and precise object detection with the Datalogic SG4-RDB2, a high-performance Type 4 Area Sensor designed for industrial safety applications. With a detection range of up to 2 meters and advanced short-circuit protection, this sensor meets the highest global safety standards, making it ideal for automated machinery, robotics, and hazardous area protection.

Key Features:

• Model: SG4-RDB2

• Detection Range: Up to 2 meters

• Protected Height: 500 mm to 1200 mm

• Sensor Type: Area Sensor

• Accuracy: 100%

• Active Area: 10 mm

• Outputs: 2 PNP outputs with short-circuit protection

  • Output Current: Max 0.5 A each

  • ON Voltage: Supply voltage - 1V

  • OFF Voltage: Max 0.2V

  • Capacitive Load: 2.2 µF @ 24VDC

• Activation Current: 15 mA

• Power Supply: 24 VDC ± 20%

• Power Consumption (RX Unit): Max 6.5 W (without load)

• Operating Temperature: -10°C to +55°C

• Storage Temperature: -20°C to +75°C

• Response Time: 11 – 24 ms

• Weight: 30 g

• Color: Black

• Body Material: Rugged and compact design

Safety Compliance:

• Type 4 (EN 61496-1)

• SIL 3 (EN 61508)

• SIL CL 3 (EN 62061)

• PL e Cat. 4 (IEC 13849-1:2008)

Applications:

✅ Machine safeguarding
✅ Industrial automation
✅ Packaging and assembly lines
✅ Safety monitoring for moving equipment
