Datalogic S300-PA-2-B01-OC Photoelectric Sensor | High-Accuracy Detection | PBT Housing | IP67

The Datalogic S300-PA-2-B01-OC is a high-performance photoelectric sensor designed to deliver accurate and reliable object detection in demanding industrial environments. Featuring a rugged PBT housing, advanced optical sensing, and flexible configuration, this sensor is ideal for precision automation applications.

🔍 Product Highlights:

• Model: S300-PA-2-B01-OC

• Sensor Type: Photoelectric Sensor

• Material: Durable PBT plastic

• Color: Black

• Accuracy: 100%

• Active Sensing Area: 5 mm

• Operating Temperature: -25°C to +50°C

• Weight: 40 g

⚡ Power & Performance:

• Power Supply Options:

  • 12–30 VDC (S300…2 models)

  • 24–240 VAC / 24–60 VDC (S300…1 models)

• Ripple: 10% max

• Power Consumption:

  • 35 mA max (S300…2)

  • 3 VA max (S300…1)

💡 Light Emission Types:

• Red LED: 660 nm (S300…B)

• Infrared LED:

  • 940 nm (S300…C)

  • 880 nm (S300…A/G/M)

⚙️ Configuration & Adjustments:

• Sensitivity Trimmer: (S300…A/B/C/F)

• DARK/LIGHT Mode DIP Switch: (S300…A/B/C/F/M)

• 7-Turn Distance Adjustment Trimmer: (S300…M)

• Timing Functions (via DIP Switch):

  • ON Delay

  • OFF Delay

  • ON-OFF Delay

  • Single Pulse (ONE-SHOT)

• Timing Trimmer: (S300…x06)

🔌 Output Specifications:

• Output Types:

  • PNP/NPN Open Collector (S300…2)

  • Electromechanical SPDT Relay – 250 VAC / 30 VDC (S300…1)

• Output Current:

  • 100 mA (S300…2)

  • 3 A max (S300…1)

• Saturation Voltage: 2.4 V max

🔋 Indicator LEDs:

• Yellow OUTPUT LED (excluding S300...G)

• Green STABILITY & POWER LEDs (S300...G)

Ideal For: Industrial automation, object detection, machine control, and position sensing applications requiring stable and accurate photoelectric sensing.
