🔧 IFM RO3110 Incremental Encoder – Hollow Shaft | IO- | High Resolution | IP67

Engineered for industrial precision, the IFM RO3110 is a robust incremental encoder designed to deliver reliable position and rotational speed detection. Featuring a three-phase output, IO- interface, and a hollow shaft design, this encoder combines flexibility with rugged durability for demanding applications.

🔍 Key Features:

• 📏 High Resolution: Programmable from 1 to 10,000 pulses (Factory default: 1024)

• 🔄 Output Type: Three-phase incremental signals for accurate speed feedback

• 🌐 Connectivity: IO- enabled for easy setup, diagnostics, and integration

• 🧲 Sensing Technology: Magnetic sensing system for exceptional shock resistance

• 🛠 Shaft Design: 15 mm hollow shaft open to one side for quick and secure installation

• 💧 Ingress Protection: IP67-rated stainless steel housing for harsh industrial conditions

📐 Technical Specifications:

• Brand: IFM

• Model/Type: RO3110

• Sensor Type: Encoder

• Encoder Type: Incremental Encoder

• Material: Stainless Steel

• Color: Silver

• Output Reading: Three Phase

• Voltage: 32 V

• Frequency: 50 / 60 Hz

• Output Frequency: 600 Hz

• Maximum Output Current: 15 mA

• Shaft Diameter: 15 mm

• Weight: 665 g

• Temperature Range: -40°C to +85°C

• Protection Rating: IP67

• Communication Interface: IO-

• MTTF (Mean Time To Failure): 292

• Max Starting Torque: 2

• Application: Industrial automation and motion control

✅ Benefits:

• ✔️ High precision feedback with customizable resolution

• ✔️ Reliable performance in extreme temperatures and industrial environments

• ✔️ Fast, tool-free integration with IO- communication

• ✔️ Built to withstand shocks, vibrations, and contaminants

Enhance your control systems with the IFM RO3110—a high-accuracy, heavy-duty encoder built for industrial reliability and long-term performance.
