RLK61-LL-IR-Z/31/135 P&F Fiber Optic Sensor – Industrial Automation | krishna-machinery-tools-kmt

🔦 P&F RLK61-LL-IR-Z/31/135 Fiber Optic Sensor Head | Red LED | IO- | IP67

The P&F RLK61-LL-IR-Z/31/135 is a high-performance fiber optic sensor head engineered for cost-effective, reliable object detection in standard industrial applications. Designed with a compact cubic housing and M30 threaded mount, this sensor offers flexible installation, robust IP67 protection, and easy visibility with 360° high-brightness status LEDs.

⚙️ Key Features:

• 🔴 Red LED Light Source for clear and reliable detection

• 💾 IO- Interface for smart sensor communication and remote diagnostics

• 🧠 Programmable Timing Functions: ON-delay, OFF-delay, One-shot

• 🔄 Switching Frequency: 500 Hz – supports fast response applications

• 🧱 Compact Stainless Steel Housing with M8 connector for durability

• 🌐 Universal Voltage Version (10–30 V DC)

• 💡 Includes Universal Fiber Adapter Kit for flexible sensing needs

• 💧 IP67 Rated for use in demanding industrial environments

📐 Technical Specifications:

• Brand: Pepperl+Fuchs (P&F)

• Model: RLK61-LL-IR-Z/31/135

• Type: Fiber Optic Sensor Head

• Light Source: Red LED

• Voltage: 10–30 V DC

• Switching Frequency: 500 Hz

• Interface: IO-

• No Load Supply Current: 35 mA

• Housing Material: Stainless Steel

• Housing Type: M8 cubic with M30 thread

• Protection Rating: IP67

• Operating Temperature: -40°C to +100°C

• Dimensions: 45 mm (H) × 73.7 mm (W) × 48.6 mm (D)

✅ Ideal For:

• Standard object detection tasks

• Space-constrained industrial automation setups

• Applications requiring smart diagnostics and timing control

• Use in harsh environments with high dust or moisture exposure

Bring precision, flexibility, and durability to your automation setup with the P&F RLK61-LL-IR-Z/31/135 Fiber Optic Sensor Head — engineered to perform under pressure.
