PRT30-15DC Autonics Proximity Sensor – Industrial Automation Sensor | krishna-machinery-tools-kmt

Autonics PRT30-15DC Inductive Proximity Sensor | 15mm Sensing | M30 | NPN Output

The Autonics PRT30-15DC is a rugged, high-performance inductive proximity sensor engineered for industrial automation and metal detection applications. With a wide 15mm sensing distance and M30 sensing head, it offers non-contact detection with high accuracy, durability, and reliable output.

Key Features:

• Brand: Autonics

• Model Number: PRT30-15DC

• Sensor Type: Inductive Proximity Sensor

• Usage/Application: Industrial automation and control

• Sensing Distance: 15 mm (Non-flush)

• Sensing Side Diameter: M30

• Standard Sensing Target: 45×45×1 mm (iron)

• Response Frequency: 200 Hz

• Operating Frequency: 200 Hz

• Power Supply Voltage: 12 – 24 V DC (2-wire type)

• Control Output: NPN

• Maximum Load Current: 45 mA

• Leakage Current: Minimal

• Operating Temperature: -25°C to +70°C

• Body Material: Stainless Steel

• Protection Rating: IP65

• Power Consumption: 3.5 V (typical)

Applications:

• Factory automation lines

• Metal object detection

• Conveyor system monitoring

• Industrial process control

Why Choose the PRT30-15DC?
With its stainless steel housing, large sensing range, and robust design, the PRT30-15DC is built to perform in demanding industrial environments. Its non-flush installation and reliable NPN output make it ideal for precise object detection where durability and accuracy are essential.
