Autonics PRL08-1.5DN2 Inductive Proximity Sensor | M08 | 1.5mm Sensing Distance | IP67 Rated

The Autonics PRL08-1.5DN2 is a compact and durable inductive proximity sensor designed for precise metal detection in tight industrial spaces. With a sensing distance of 1.5mm and flush mounting in an M08 stainless steel housing, it is ideal for automation applications requiring reliable operation in harsh conditions.

Key Specifications:

• Brand: Autonics

• Model: PRL08-1.5DN2

• Sensor Type: Inductive Proximity Sensor

• Sensing Distance: 1.5 mm

• Sensing Side Diameter: M08 (Flush)

• Standard Sensing Target: 8×8×1 mm (iron)

• Power Supply Voltage: 10 – 30 V DC

• Maximum Load Current: 10 mA

• Response Frequency: 1.5 kHz

• Operating Frequency: 50 Hz

• Body Material: Stainless Steel

• Ambient Temperature: -25°C to +75°C

• Protection Rating: IP67

• Weight: 54 g

• Usage/Application: Industrial sensing and automation

Features:

• Ultra-compact M08 housing ideal for confined installation areas

• IP67-rated protection for resistance to dust, water, and oil

• High-speed response with a frequency of 1.5 kHz

• Excellent performance for detecting metallic objects in automated environments

• Flush mounting ensures space efficiency and protection from mechanical damage

Upgrade your industrial automation systems with the Autonics PRL08-1.5DN2—a smart choice for precise, rugged, and efficient proximity sensing.
