PNI024 IFM Pressure Sensor – Industrial Pressure Measurement Sensor | krishna-machinery-tools-kmt

Multifunction Digital Pressure Sensor | 0–10 Bar | G 1/4" | Dual Output | LED Display

Upgrade your industrial monitoring with this advanced digital pressure sensor, engineered for precision pressure measurement in both liquid and gas applications. With a measuring range of 0–10 bar, dual digital outputs, and robust stainless steel construction, this sensor is ideal for a wide range of demanding environments.

Key Features:

• Pressure Range: 0...10 bar (Relative Pressure)

• Output Type: 2 x Digital (PNP/NPN configurable)

• Output Function: Normally Open / Normally Closed (parameterisable)

• Connection Type: G 1/4" internal thread (threaded)

• Electrical Connection: M12 Connector with gold-plated contacts

• Response Time: < 3 ms

• Switching Frequency: < 170 Hz

• Display: 4-digit alphanumeric LED + status LEDs (green/yellow)

• Power Supply: 18–30 V DC

• Housing Material: Stainless Steel (1.4305), PBT, PC, PA, FKM

• Wetted Parts: Stainless Steel, Ceramics, FKM

• Operating Temperature: -25°C to +80°C

• Storage Temperature: -40°C to +100°C

• Protection Rating: IP65

• Vibration/Shock Resistant: 20 g / 50 g

• MTTF (Mean Time To Failure): 152 years

• Weight: 289 g

Advanced Functionality:

• Integrated analogue input (0–20 mA / 0–10 V)

• Selectable display units: bar, psi, MPa

• Programmable switching logic, delay, damping, and hysteresis/window modes

• Display orientation and backlight options

• Reverse polarity & short-circuit protection

• High burst pressure: up to 150 bar

• High durability: >100 million pressure cycles

Applications:

• Pneumatics & compressed air systems

• Liquid & gas pressure monitoring

• Machine & process automation

• OEM integration in hydraulic systems

Ensure accurate, repeatable, and durable pressure sensing in even the harshest conditions. Whether you're integrating into a new system or upgrading existing equipment, this sensor delivers industry-grade performance and configurability.
