IFM PN7060 Pressure Sensor – High-Performance IO- Enabled Sensor (0–600 bar)

Engineered for precision and resilience, the IFM PN7060 Pressure Sensor is designed to monitor relative pressure in demanding industrial applications. With a wide measuring range of 0 to 600 bar (8700 psi / 60 MPa), this sensor is ideal for both liquid and gas media, ensuring reliable performance even under extreme conditions.

🔧 Key Features:

• Dual Digital Outputs: Includes 2 configurable digital outputs with IO- support.

• Measurement Range: 0...600 bar | 0...8700 psi | 0...60 MPa.

• Gold-Plated Contacts ensure superior electrical performance and corrosion resistance.

• Versatile Process Connection: G 1/4 internal thread with rotatable housing for easy alignment.

• High Overpressure Protection: Pressure rating up to 800 bar, withstanding bursts up to 2500 bar.

• Fast Response Time: < 3 ms with programmable delay (0–50 s).

• Robust Design: Built for harsh environments with IP65/IP67 protection, shock (50 g) and vibration (20 g) resistance.

📟 Display & Diagnostics:

• Large 4-digit alphanumeric red/green LED display.

• 3 green LEDs for pressure units (bar, psi, MPa) and 2 yellow LEDs for switching status.

• Visual confirmation of safe/unsafe pressure zones.

• Supports IO- (COM2, V1.1) for real-time diagnostics and remote parameterization.

⚙️ Technical Specifications:

• Output Types: PNP/NPN, normally open/closed (parameterizable).

• Switching Frequency: Up to 170 Hz.

• Accuracy:

  • Switching point: ±0.5% of span

  • Repeatability: ±0.1%

  • Long-term stability: ±0.05% per 6 months

• Operating Temp: -25 to +80 °C
  Storage Temp: -40 to +100 °C

• Electrical Connection: M12 Connector, gold-plated contacts.

• MTTF (Mean Time To Failure): 214 years.

🧱 Construction & Materials:

• Wetted Parts: Stainless Steel (630/17-4 PH)

• Housing Materials: Stainless Steel 316L, PBT-GF30, PC

• Compact Design: Ø34 mm x 90.7 mm

• Weight: 231.5 g

• Minimum Pressure Cycles: 100 million

✅ Compliance & Approvals:

• UL Approved (No. J003)

• EMC Compliant: DIN EN 61000-6-2, EN 61000-6-3

• Shock & Vibration Resistance: DIN EN 60068-2 standards

• Complies with Pressure Equipment Directive (for group 2 fluids)

Ideal for machine building, hydraulics, pneumatics, and automation systems, the IFM PN7060 provides unmatched reliability, fast integration, and long-term stability even under high loads.

Pack Quantity: 1 unit
Part Number: PN7060
