PN7097 IFM Pressure Sensor – Industrial Pressure Measurement Sensor | krishna-machinery-tools-kmt

Industrial Pressure Sensor with IO- Communication | Model PN7007

Reliable, Accurate, and Smart Pressure Monitoring for Industrial Applications

Engineered for high-precision performance in challenging environments, the PN7007 Pressure Sensor offers exceptional measurement reliability, durability, and smart communication features. Ideal for monitoring liquids and gases in industrial systems, this sensor features a robust stainless steel construction, configurable outputs, and IO- interface for seamless integration and diagnostics.

Key Features:

• Pressure Measuring Range:

  • 0…1 bar | 0…1000 mbar | 0…14.5 psi | 0…29.5 inHg | 0…100 kPa

  • Type of Pressure: Relative

• Outputs & Interface:

  • 2 Digital Outputs (PNP/NPN configurable)

  • IO- Communication (COM2, Rev 1.1, Smart Sensor Profile)

  • Switching signal, binary and analog process data

• High Precision Performance:

  • Switch point accuracy: ±0.5% of span

  • Repeatability: ±0.1%

  • Long-term stability: ±0.05% per 6 months

  • Response time: <3 ms

• Durable Construction:

  • Housing: Stainless steel 316L, PBT-GF20

  • Wetted Parts: Stainless steel 316L, Ceramic, FKM

  • IP65/IP67 protection for harsh environments

  • Pressure rating up to 1000 kPa / 145 psi

  • Burst pressure: 3000 kPa / 450 psi

• Environmental Tolerance:

  • Operating temperature: -25°C to 80°C

  • Storage temperature: -40°C to 100°C

  • Shock resistance: 50 g (11 ms), Vibration: 20 g (10…2000 Hz)

• User-Friendly Design:

  • Red/Green LED Display for clear pressure range indication

  • 4-digit alphanumeric display for precise readings

  • Configurable settings for hysteresis/window, logic, damping, display unit, delays

  • Rotatable process connection for flexible installation

• Electrical Specs:

  • Operating voltage: 18…30 V DC

  • Current consumption: <35 mA

  • Reverse polarity & short-circuit protection

  • M12 Connector with gold-plated contacts

Applications:

• Industrial automation

• Liquid and gas systems

• Pneumatics and hydraulics

• OEM machinery requiring long-term stability and digital diagnostics

Part Number: PN7007
Mounting: G 1/4 Internal Thread
Weight: 234.5 g
Pack Quantity: 1 Piece
Compliance: CE, UL, EMC, PED Sound Engineering Practice
MTTF: 260 years

💡 Why Choose This Sensor?
With IO- support, enhanced signal clarity, and rugged mechanical design, the PN7007 stands out as a reliable and intelligent choice for modern pressure monitoring systems.
