PN7094 IFM Pressure Sensor | Industrial Pressure Sensor – krishna-machinery-tools-kmt

PN7004 Pressure Sensor with IO- | -1 to 10 bar Range

Smart, Durable & High-Precision Pressure Sensor for Industrial Applications

The PN7004 is a highly reliable pressure sensor designed for demanding industrial environments. Featuring a robust stainless steel body, dual digital outputs, and advanced IO- communication, this sensor provides precise monitoring of relative pressure and vacuum in liquid and gas systems.

Key Features:

• Measuring Range:

  • -1 to 10 bar | -14.5 to 145 psi | -0.1 to 1 MPa

  • Type: Relative pressure & vacuum

• Output & Communication:

  • 2 Digital Outputs (configurable PNP/NPN)

  • IO- communication (COM2, Rev. 1.1)

  • Switching signal & binary/analog process data

  • Output functions: Normally Open / Normally Closed (parameterisable)

• High Accuracy Performance:

  • Switch point accuracy: < ±0.5%

  • Repeatability: < ±0.1%

  • Long-term stability: < ±0.05% over 6 months

  • Response time: < 3 ms

  • IO- resolution: 0.005 bar / 0.0005 MPa

• Rugged Industrial Design:

  • Housing: Stainless steel 316L, PBT-GF20

  • Wetted Parts: 316L stainless steel, ceramics, FKM

  • IP65 / IP67 Protection Rating

  • Pressure Rating: 75 bar (1087 psi)

  • Burst Pressure: 150 bar (2175 psi)

  • 100 million+ pressure cycle lifespan

• Environmental Capabilities:

  • Operating Temperature: -25 to 80 °C

  • Storage Temperature: -40 to 100 °C

  • Shock resistance: 50 g (11 ms), Vibration: 20 g (10–2000 Hz)

• Display & Configuration:

  • 4-digit alphanumeric red/green display

  • LED indicators for pressure unit (bar/psi/MPa) and switching status

  • Rotatable process connection for flexible mounting

  • Configurable hysteresis, window function, delays, logic, and units

• Electrical Data:

  • Voltage: 18–30 V DC

  • Current Consumption: <35 mA

  • Short-circuit, reverse polarity & overload protection

  • Connector: M12, gold-plated contacts

  • Power-on delay: < 0.3 s

Applications:

• Pneumatics & Hydraulics

• Industrial automation systems

• Process control in harsh environments

• Liquid and gas media monitoring

Model No.: PN7004
Mounting: G 1/4 Internal Thread
Weight: 241.7 g
Dimensions: Ø 34 mm x L 90.7 mm
Compliance: EMC, CE, UL Listed
MTTF: 260 Years
Pack Quantity: 1 Unit

💡 Why Choose PN7004?
Experience unmatched stability, intelligent diagnostics via IO-, and high-performance sensing in a compact, robust design — perfect for modern industrial applications.
