PN7060 IFM Pressure Sensor | Industrial Pressure Sensor – krishna-machinery-tools-kmt

Digital Pressure Sensor – 0...600 bar | IO- Compatible | G 1/4 Connection

Reliable, high-performance pressure monitoring for industrial applications.

This digital pressure sensor is engineered for precision and durability in demanding environments. With a broad measuring range of 0...600 bar (0...8700 psi / 0...60 MPa), it is ideally suited for monitoring liquids and gases in industrial systems.

Key Features:

• Measurement Range: 0...600 bar / 0...8700 psi / 0...60 MPa

• Output: 2 programmable digital outputs (PNP/NPN), configurable as normally open or normally closed

• Process Connection: G 1/4 internal thread

• Display: 4-digit red/green LED with selectable units (bar, psi, MPa)

• IO- Communication: Supports COM2, IO- v1.1 for advanced data transfer and diagnostics

• Switching Points:

  • SP1 = 150 bar, rP1 = 138 bar

  • SP2 = 450 bar, rP2 = 438 bar (factory settings)

• Repeatability & Accuracy:

  • Switching accuracy: < ±0.5% of span

  • Repeatability: < ±0.1%

  • Long-term stability: < ±0.05% per 6 months

Durability You Can Trust:

• Overload & Burst Pressure Ratings:

  • Rated: 800 bar (11600 psi)

  • Burst: 1200 bar (17400 psi)

• Environmental Protection: IP67-rated housing for reliable performance in harsh industrial conditions

• Robust Construction: Stainless steel body (630/1.4542) with gold-plated electrical contacts

Electrical & Functional Specifications:

• Operating Voltage: 18–36 V DC

• Current Consumption: < 35 mA

• Protection: Reverse polarity, overvoltage (< 40 V), and short-circuit protection (pulsed)

• Response Time: < 3 ms

• Switching Frequency: < 170 Hz

• Temperature Range:

  • Medium: -25 to 80 °C

  • Ambient: -20 to 80 °C

  • Storage: -40 to 100 °C

Smart Software Functions:

• Hysteresis/window mode

• Switch-on/switch-off delay

• Diagnostic functions

• Damping configuration

• IO- process and diagnostic data access

Compliance & Approvals:

• EMC Standards: EN 61000-4-2/3/4/5/6

• Shock/Vibration Resistance: 50 g / 20 g

• MTTF: 219 years

• UL Certified

Ideal for integration in hydraulic and pneumatic systems, this sensor provides accurate pressure feedback and remote configurability for seamless automation and diagnostics.
