PN2293 IFM Pressure Sensor | Industrial Pressure Sensor – krishna-machinery-tools-kmt

IFM Industrial Pressure Sensor | -1 to 25 Bar | Dual Digital & Analog Output | IO- | 1/4" NPT

Versatile, Intelligent, and Built to Last – The Ultimate Pressure Monitoring Solution

This advanced IFM pressure sensor delivers outstanding performance for demanding industrial applications involving liquids and gases. Designed with cutting-edge ceramic-capacitive sensing, gold-plated contacts, and flexible output options, it ensures high accuracy, long-term stability, and easy integration into any automation setup.

Key Features:

• Measuring Range:
  -1 to 25 bar | -14.5 to 362.5 psi | -0.1 to 2.5 MPa
  Vacuum compatible down to -1000 mbar (-0.1 MPa)

• Pressure Rating:

  • Operating: 150 bar (2175 psi)

  • Bursting: 350 bar (5075 psi)

  • MAWP (CRN compliant): 70 bar (1015 psi)

• Process Connection:
  1/4" NPT internal thread – ideal for North American industrial setups

• Output Configuration:

  • 2 Digital Outputs (PNP/NPN, parameterizable)

  • 1 Analog Output (4–20 mA or 0–10 V, scalable 1:5)

  • IO- Communication for advanced diagnostics and remote configuration

Electrical and Environmental Specs:

• Supply Voltage: 18–30 V DC (SELV/PELV)

• Current Consumption: < 35 mA

• Max Load: 500 Ω (current), Min Load 2000 Ω (voltage)

• Switching Frequency: < 500 Hz

• Short-Circuit & Overload Protection: Yes (pulsed type)

• Reverse Polarity Protection: Yes

• Protection Class: III

Mechanical & Design Features:

• Sensor Technology: Ceramic-capacitive

• Media Compatibility: Liquids & gases

• Medium Temperature: -25 to +80°C

• Display: Bright Red/Green LED display for clear operating range visibility

• Rotatable Process Connection for optimal alignment during installation

• Gold-Plated Contacts for high conductivity and signal reliability

• Robust IP-rated design for harsh environments

Applications:

• Industrial automation

• Hydraulic and pneumatic systems

• Process monitoring

• Gas and liquid pressure regulation

• Systems requiring dual output flexibility and remote control via IO-

With dual digital outputs, analog signal, IO- support, and a rugged design, this IFM pressure sensor offers unmatched precision, flexibility, and long-term performance in a compact form.
