PN2094 IFM Pressure Sensor | Industrial Pressure Sensor – krishna-machinery-tools-kmt

IFM Pressure Sensor | -1 to 10 bar | IO- + Analog Output | Dual Digital Outputs | G 1/4 Thread

Reliable Pressure Monitoring for Industrial Liquids and Gases

Enhance your industrial automation system with this precision-engineered IFM pressure sensor. Designed to handle a wide range of media, it features ceramic-capacitive sensing technology, dual digital outputs, analog signal output, and IO- compatibility—all built into a rugged, compact body that ensures long-lasting performance in harsh environments.

✅ Key Features:

• Measuring Range:

  • -1 to +10 bar

  • -14.6 to +145 psi

  • -0.1 to +1 MPa

• Pressure Type:

  • Relative pressure & vacuum

  • Vacuum resistance: -1000 mbar (-0.1 MPa)

  • Max Pressure Rating: 75 bar (1087 psi)

  • Bursting Pressure: 150 bar (2175 psi)

• Application Compatibility:

  • Designed for liquids and gases

  • Ideal for industrial automation, hydraulics, pneumatics, and process control

• Sensor Core:

  • Ceramic-capacitive pressure measuring cell

  • Gold-plated electrical contacts for superior conductivity

⚙️ Outputs & Electrical Specifications:

• Outputs (3 Total):

  • 2 Digital Outputs:

    • Configurable as Normally Open / Normally Closed

    • Electrical design: PNP/NPN

    • Max current: 250 mA

    • Switching frequency: < 500 Hz

  • 1 Analog Output:

    • Current: 4–20 mA (max load: 500 Ω)

    • Voltage: 0–10 V (min load: 2000 Ω)

    • Scalable ratio: 1:5

  • IO- Support: Yes (for advanced monitoring and diagnostics)

• Operating Voltage: 18–30 V DC

• Current Consumption: < 35 mA

• Protection:

  • Reverse polarity protection

  • Short-circuit and overload protection (pulsed type)

  • Protection Class: III

  • Integrated watchdog function

  • Power-on delay: 0.3 seconds

🛠️ Mechanical & Design Features:

• Process Connection:

  • G 1/4 internal thread (DIN EN ISO 1179-2)

  • Rotatable process connection for flexible alignment

• Operating Temperature Range:

  • -25°C to +80°C

• Display:

  • Red/green LED indicator for clear status visibility

• Build Quality:

  • Engineered for harsh industrial environments

  • Excellent long-term stability and shock resistance

📦 Ideal Applications:

• Industrial automation systems

• Pneumatics and hydraulics monitoring

• Process control lines

• Machine tool integration

• OEM systems requiring compact, robust sensors

Get advanced pressure control, robust design, and IO- connectivity—perfectly tailored for demanding industrial operations. Trust IFM’s quality engineering to power your automation.
