Panasonic PM-U25-P Ultra-Small U-Shaped Photoelectric Sensor | 6 mm Fixed Sensing | IP65 Rated

Compact Detection. Built-In Amplifier. Industrial-Grade Performance.

The Panasonic PM-U25-P is an ultra-compact U-shaped photoelectric sensor engineered for precise object detection in tight spaces. With a built-in amplifier and robust cable-type design, it offers a 6 mm fixed sensing range and exceptional reliability, making it ideal for a wide range of industrial automation and machine-building applications.

🔍 Key Features:

• Fixed Sensing Distance: 6 mm

• Ultra-Compact U-Type Housing for limited-space installation

• High Detection Accuracy: Capable of sensing opaque objects as small as 0.8 × 1.2 mm

• Built-In Amplifier: No need for an external unit

• Cable Type Configuration for easy integration

• IP65 Protection: Suitable for dusty and moist environments

⚙️ Technical Specifications:

• Model Number: PM-U25-P

• Brand: Panasonic

• Material: PBT

• Accuracy: 100%

• Activation Current: 15 mA

• Active Area: 100 mm

• Operating Temperature: -25°C to +70°C

• Weight: 10 g

• Protection Rating: IP65

• Sensing Range: 6 mm (fixed)

• Minimum Sensing Object: 0.8 × 1.2 mm (opaque)

✅ Certifications & Standards:

• CE Marking (EMC & RoHS Directives)

• UKCA Marking (EMC & RoHS Regulations)

• ISO 13849-1 (Category 1, PLc — Conformed from Dec 2021)

• UL/c-UL Recognition Certified

The PM-U25-P combines ultra-compact design and powerful sensing capabilities, making it a top choice for high-speed, precision industrial automation setups where space and reliability matter.
