Panasonic PM-R65-P U-Shaped Micro Photoelectric Sensor | Compact Built-In Amplifier | R Type

High-Precision Detection in a Miniature Design

The Panasonic PM-R65-P is a compact, high-performance U-shaped photoelectric sensor equipped with a built-in amplifier. With its R-type connector and robust sensing capabilities, it is ideal for space-constrained installations in industrial automation environments.

🔧 Key Specifications:

• Model No.: PM-R65-P

• Brand: Panasonic

• Sensor Type: Photoelectric Sensor (Amplifier Built-in)

• Material: PBT

• Color: Black

• Weight: 3 g

• Active Area: 30 mm

• Sensing Range: 6 mm (Fixed)

• Minimum Sensing Object: 0.8 × 1.2 mm (opaque object)

• Hysteresis: ≤ 0.05 mm

• Repeatability: ≤ 0.01 mm

• Operating Temperature: -25°C to +55°C

• Protection Rating: IP40

• Supply Voltage: 5 to 24 V DC ±10%

• Current Consumption: ≤ 15 mA

• Activation Current: 20 mA

• Product Series: R Type (Compact / Connector Built-in Type)

✅ Features & Benefits:

• Ultra-compact design with integrated amplifier

• Connector-type construction for easy integration

• Highly accurate with minimal hysteresis and excellent repeatability

• Certified for CE, UKCA, UL/c-UL standards

• Ideal for high-speed, small-object detection in automated systems

Whether you're upgrading your sensing technology or building a new automation system, the Panasonic PM-R65-P delivers unmatched reliability in a space-saving form factor.
