PM-K25 Panasonic Micro Photoelectric Sensor | Industrial Automation Sensor – krishna-machinery-tools-kmt

Panasonic Compact Photoelectric Sensor | NPN Output | 6 mm Sensing Range | IP64 Rated

Enhance your automation precision with this compact Panasonic photoelectric sensor, engineered for high reliability in tight spaces. Featuring an integrated amplifier, dual output modes (Light-ON / Dark-ON), and robust environmental protection, this sensor is ideal for detecting small opaque objects in demanding industrial environments.

🔧 Technical Specifications:

• Material: PBT

• Accuracy: 100%

• Active Area: 8 mm

• Weight: 10 g

• Protection Rating: IP64

• Operating Temperature: -25°C to +70°C

• Sensing Range: 6 mm (fixed)

• Minimum Detectable Object: 0.8 × 1.2 mm opaque

• Repeatability: ±0.01 mm

• Hysteresis: ≤ 0.05 mm

• Supply Voltage: 5–24 V DC ±10%

• Ripple: ≤ 10% (P-P)

• Current Consumption: ≤ 15 mA

• Output Type: NPN open-collector transistor

  • Max sink current: 50 mA

  • Max voltage: 30 V DC

  • Residual voltage: ≤ 2 V @ 50 mA / ≤ 1 V @ 16 mA

• Output Operation: Dual outputs – Light-ON / Dark-ON

• Short-Circuit Protection: Included

✅ Key Features:

• Dual Output Modes for versatile application (Light-ON / Dark-ON)

• High Precision Sensing with ultra-low hysteresis

• Compact and Lightweight — ideal for space-limited setups

• Certified Safe: CE (EMC, RoHS Directives)

• Durable Build with IP64 protection against dust and splashes

📦 Applications:

• Part positioning and detection

• Robotics and pick-and-place systems

• Conveyor systems

• High-speed packaging lines

Optimize your automation workflow with this high-precision Panasonic photoelectric sensor — compact, responsive, and built to perform under pressure.
