PCT-102-21 Metcal Soldering Rework Station | krishna-machinery-tools-kmt

Power 130 W Temperature Range -10-60 Weight 2 Kg Model Name/Number PCT-102-21 Adjustable Temperature Yes Dimensions 205mm (L) x 155mm (W) x 65mm (H) 8.07" (L) x 6.10" (W) x 2.56" (H) Material Metal & Plastic METCAL PCT-102-21 Focused Convection Pre-Heater with Arm Rest and Board holder 450W 230V AC, Metcal PCT-102-21 Focused Pre-Heater The PCT-100 Focus Pre-heater targets heat for improved speed and efficiency for high thermal demand applications, including lead-free. Used for SMT and through-hole hand processes, the PCT-100 uses convection air heating to heat a PCB first, for better soldering, improved process control and increased productivity. The PCT-100 Focus Pre-heater adds heat volume, without turning up the temperature, to perform assembly tasks at the appropriate peak temperature without distorting the board. Accelerates and enhances the lead-free SMT & through-hole rework process Temperature ramps up quickly, maximizing productivity Adjustable knob controls the required temperature to below 300°C Controlled cool-down eliminates thermal shock to PCB and components Thermocouple feedback temperature control regulates output temperature System safety feature automatically shuts off heating when fan is stopped ESD safe Includes board holder and arm rest Contents Focus Pre-heater, Arm Rest, Free-standing board holder, Power Cord and User Guide
