IFM PA9024 Pressure Transmitter – 0–1000 PSI, 0–10 V Output, PNP, IP64

The IFM PA9024 is a compact and highly reliable industrial pressure transmitter, designed to deliver precision and stability in demanding environments. Built with a ceramic measuring cell and a robust stainless steel housing, this transmitter provides fast and accurate pressure readings with outstanding repeatability.

Key Features:

• Measurement Range: 0–1000 psi

• Output Signal: Linear 0–10 V analog output

• Output Type: PNP

• Response Time: Ultra-fast 2 ms for real-time monitoring

• Voltage Range: 10–30 V (Supply Voltage Limit: 32 V)

• Protection Rating: IP64 – Dust-proof and splash-resistant

• High Accuracy: 100% accuracy with minimal linearity error

• Repeatability: Excellent signal consistency for stable performance

• Minimum Pressure Durability: Rated for 100 million pressure cycles

• Material: Durable stainless steel housing

• Weight: 222 g

• Dimensions: Ø30 mm / Length: 75 mm

• Color: Silver

• Application: Ideal for industrial automation, fluid systems, and machinery monitoring

Model Details:

• Model Name/Number: PA9024 (PA-010-RBR14-B-DVG/US/V)

• Brand: IFM

• Technology: Ceramic Pressure Measuring Cell

• Usage/Application: Industrial

Why Choose IFM PA9024:

• Designed for long-term use with high overload protection

• Compact yet rugged construction ideal for space-limited installations

• Fast response and repeatability ensure reliable control and safety

• Suitable for various industrial applications where durability and accuracy matter

Upgrade your pressure monitoring systems with the IFM PA9024 — a trusted solution for high-performance industrial environments.
