IFM PA9022 Pressure Transmitter – 0–5000 PSI, 0–10 V Output, IP67, PNP, Stainless Steel

Built for demanding industrial environments, the IFM PA9022 pressure transmitter combines precision, durability, and fast response in a compact, rugged design. Featuring a ceramic measuring cell and a robust stainless steel housing, it ensures reliable performance under high pressure and harsh conditions.

Key Features:

• Measurement Range: 0–5000 psi

• Operating Pressure: Up to 20 bar

• Output Signal: Linear 0–10 V analog

• Output Type: PNP

• Response Time: Quick 10 ms for real-time control

• Voltage Range: 9.6–32 V (Rated Supply Voltage: 12–24 V)

• Supply Voltage Limits: 10–24 V

• Protection Rating: IP67 – Completely dust-tight and protected against water immersion

• Accuracy: 100% with low linearity error and high repeatability

• Material: Industrial-grade stainless steel

• Housing Style: Cylindrical, Ø30 mm / Length = 75 mm

• Weight: 222.5 g

• Color: Silver

Model Details:

• Model Name/Number: PA9022 (PA-100-SBR14-B-DVG/US/V)

• Brand: IFM

• Technology: Ceramic pressure measuring cell

• Application: Industrial pressure monitoring and automation

Why Choose the IFM PA9022:

• High overload protection ensures long-term stability

• Fast, precise response for efficient system feedback

• Suitable for harsh environments with IP67-rated protection

• Durable, compact construction ideal for tight installations

Rely on the IFM PA9022 for consistent, accurate pressure monitoring in your industrial systems — designed for performance, built to last.
