IFM PA3589 Pressure Transmitter – 0–5000 PSI, 4–20 mA Output, PNP, IP67, Stainless Steel

The IFM PA3589 is a high-precision industrial pressure transmitter designed for rugged applications requiring fast response, accuracy, and long-term reliability. Built with a ceramic measuring cell and enclosed in a robust stainless steel housing, it offers stable, repeatable performance even in extreme operating conditions.

Key Features:

• Measurement Range: 0–5000 psi

• Output Signal: Precise 4–20 mA analog output

• Output Type: PNP

• Voltage Range: 10–30 V

• Response Time: Rapid 5 ms response for dynamic pressure control

• Accuracy: 100% with low linearity error and excellent repeatability

• Protection Rating: IP67 – Fully dust-tight and protected against water immersion

• Ambient Temperature Range: -25°C to +80°C

• Storage Temperature Range: -40°C to +100°C

• Material: Durable stainless steel construction

• Dimensions: Ø30 mm / Length = 75 mm

• Weight: 222 g

• Color: Silver

Model Information:

• Model Number: PA3589 (PA-,10BRBG14-A-ZVG/US/V)

• Brand: IFM

• Technology: Ceramic pressure measuring cell

• Product Type: Pressure Transmitter

• Application: Designed for industrial pressure monitoring, fluid systems, and automation processes

Why Choose IFM PA3589:

• Linear 4–20 mA output ideal for control systems

• Reliable performance in harsh industrial environments

• Fast response time improves system efficiency

• Engineered for long service life with high overload protection

• Wide temperature tolerance for flexible installation

The IFM PA3589 is a rugged and reliable solution for accurate pressure monitoring in industrial systems — built to withstand the toughest environments.
