IFM PA3022 Pressure Transmitter | 0–5000 PSI | Industrial-Grade Sensor

The IFM PA3022 pressure transmitter is built for precision and reliability in demanding industrial environments. Featuring a ceramic measuring cell and robust stainless steel housing, it ensures consistent 4–20 mA output with exceptional repeatability and minimal error.

Product Highlights:

• Measurement Range: 0–5000 psi

• Accuracy: 100%

• Response Time: Ultra-fast 2 ms

• Output Signal: 4–20 mA (analog)

• Output Type: PNP

• Voltage Range: 12–24 V DC

• Rated Supply Voltage: 24 V

• Supply Voltage Limits: Up to 32 V

• Protection Type: IP67

• Model Number: PA3022 (PA-100-SBR14-A-ZVG/US/V)

• Product Weight: 216 g

• Housing Type: Cylindrical, Stainless Steel

• Dimensions: 30 mm / Length = 75 mm

• Color: Silver

• Application: Industrial use

Key Features:

• Precise and linear 4–20 mA output signal for accurate monitoring

• High repeatability with low linearity error

• Long-term stability supported by advanced overload protection

• Rugged stainless steel construction for harsh conditions

• IP67-rated protection for dust and water resistance

• Wide operating temperature range and voltage tolerance

Reliable. Durable. Accurate. The IFM PA3022 is your go-to solution for industrial pressure monitoring where performance and robustness are critical.
