P&F UB300-18GM40A-I-V1 Ultrasonic Sensor – Analog Output (4–20 mA), Compact 40 mm Design, IP67 Rated

The UB300-18GM40A-I-V1 Ultrasonic Sensor from Pepperl+Fuchs (P&F) delivers high-precision analog sensing in a short 40 mm cylindrical design, perfect for space-constrained industrial environments. With an adjustable measuring window, IP67-rated protection, and wide temperature tolerance, this sensor is ideal for demanding applications requiring non-contact, analog distance measurement.

🔧 Technical Specifications:

• Brand: Pepperl+Fuchs (P&F)

• Model: UB300-18GM40A-I-V1

• Sensor Type: Ultrasonic

• Switching Mode: Normally Closed (NC)

• Output Type: Analog (4 mA to 20 mA)

• Sensing Distance: 10 mm

• Measuring Window: Adjustable

• Switching Frequency: 390 kHz

• Response Frequency: 390 kHz

• Power Supply Voltage: 10 to 30 V DC (Typical: 12 to 24 V DC)

• Connection Type: Cable, 2-Wire

• Body Style: Cylindrical, flush-mount design

• Body Material: Stainless Steel

• Installation Type: Flush

• Operating Temperature: -40°C to +105°C

• Degree of Protection: IP67 – Fully sealed against dust and water

• Indicators: Function indicators visible from all directions

• Usage/Application: Industrial automation, object detection, distance measurement

⚙️ Key Features:

• ✅ Analog Output (4–20 mA) – Ideal for continuous level or distance monitoring

• ✅ Compact 40 mm Body – Designed for installations with limited space

• ✅ Adjustable Measuring Window – Customize detection range to your application

• ✅ High Switching Frequency (390 kHz) – Ensures fast, accurate detection

• ✅ Durable Stainless Steel Housing – Withstands harsh industrial conditions

• ✅ IP67 Rated – Dust-tight and water-resistant for reliable performance

🏭 Ideal for Applications Such As:

• Tank level monitoring

• Conveyor systems and packaging lines

• Robotic automation and positioning

• Industrial machinery feedback systems

• OEM equipment integration

The UB300-18GM40A-I-V1 is built for industries that demand precision, reliability, and durability in a compact sensor solution. Whether you're measuring distance, levels, or object position, this sensor delivers dependable results — even in harsh environments.
