IFM OPU201 Photoelectric Fork Sensor – Compact Precision for High-Speed Applications

The IFM OPU201 photoelectric fork sensor offers precise object detection with a fast response time and compact design. Ideal for space-constrained industrial setups, it ensures reliable operation with minimal setup effort and maximum flexibility.

Product Specifications:

• Brand: IFM

• Model Number: OPU201

• Sensor Type: Photoelectric Fork Sensor

• Material: PBT

• Accuracy: 100%

• Activation Current: 15 mA

• Active Area: 8 mm

• Operating Voltage: 10–30 V (DC)

• Electrical Design: PNP

• Type of Light: Red Light (660 nm)

• Switching Frequency: 5000 Hz

• Operating Temperature: -25 to 75 °C

• Dimensions: 40 x 10 x 50 mm

• Fork Depth: 25 mm

• Fork Width: 20 mm

• Weight: 74 g

• Protection Rating: IP67

Key Features:

• Easy Installation: No need to align transmitter and receiver

• Consistent Accuracy: Fine, precise light beam across the entire fork width

• Rugged Design: Metal housing reduces distortion in harsh environments

• Flexible Modes: Light-on/dark-on selection via rotary switch

• Adjustable Sensitivity: Intuitive control through built-in potentiometer

Engineered for performance and reliability, the IFM OPU201 is the smart choice for fast, accurate detection in modern automation systems.
