OPS2X3-40-48-A-1-CU Selec Open Frame Power Supply | Industrial Power – krishna-machinery-tools-kmt

OPS2x3-40-48-A-1-CU | 40W Open Frame Power Supply – 48V DC Output

Upgrade your automation systems with the OPS2x3-40-48-A-1-CU, a compact and energy-efficient 40W open frame SMPS designed for high-performance industrial use. Built with a robust mild steel enclosure and IP67-rated protection, this power supply is reliable even in the harshest environments.

⚙️ Technical Specifications:

• Model: OPS2x3-40-48-A-1-CU

• Series: OPS 40W Series

• Output Power: 40W

• Output Voltage: 48V DC

• Input Voltage: 90 – 264 VAC

• Output Current: 15 mA

• Current Rating: 30A

• Form Factor: 3" x 2" x 1.16"

• Frequency Range: 47 – 63 Hz

• Display: LED

• Rise Time: 100 ms

• Material: Mild Steel

• Color: Grey

• Weight: 100 g

• Cable Included: Yes

• Mounting: Open Frame

• Protection Rating: IP67

• Operating Temperature: -40°C to +85°C

• Storage Temperature: -40°C to +85°C

• Phase: Single Phase

• Portable: Yes

✅ Key Features:

• High Efficiency: Up to 86% efficiency with convection cooling

• Robust Safety: Thermal shut-down, 2xMOPP protection, and Medical (BF) approvals

• Reliable Build: IP67 protection and durable mild steel housing

• Energy-Saving: < 0.5W no-load power consumption

• Compact Design: Fits easily in space-constrained industrial panels

• Compliant with Global Standards: Approved for Household, ITAV & Medical applications

• Automatic Operation & Easy Installation: Comes with included cable and optional installation service

Perfect for industrial automation, medical electronics, and embedded systems, the OPS2x3-40-48-A-1-CU ensures safe, reliable, and efficient power delivery.
