Omron E32-ZC200 Fiber Optic Sensor | High-Precision | krishna-machinery-tools-kmt

Voltage 10-30V Brand Omron Type Fiber Optics Sensor Heads Light Source Infrared LED Interface IO- Model Number E32-ZC200 Switching Frequency 50 /60 Hz Switching Output PNP Housing M8 Housing Material Plastic Degree of Protection IP67 Operating Temperature -40 to 125 Deg C No Load Supply Current 15 mA Supply voltage UB 10 ...... 30 V Device Short Name E32-ZC200 Accuracy 100 % Application Industrial Weight 65 g The optical fiber is 2m long on each side, so the sensing distance is 4,000 mm. Note 1. The following mode names and response times apply to the modes given in the Sensing distance column. [E3X-ZV] GIGA: Giga-power mode (16 ms), HS: High-speed mode (250 ?s), ST: Standard mode (1 ms), and SHS: Super-high-speed mode (50 ?s) [E3NX-FA] GIGA: Giga-power mode (16 ms), HS: High-speed mode (250 ?s), ST: Standard mode (1 ms), and SHS: Super-high-speed mode (30 ?s) 2. The values for the minimum sensing object are reference values that indicate values obtained in standard mode with the sensing distance and sensitivity set to the optimum values. The first value is for the E3X-ZV and the second value is for the E3NX-FA. 3. The sensing distances for E3NX-FA are values for E3NX-FA[] models. The distances for E3NX-FAH[] infrared models are different. 4. The E3X-HD Series offers the same sensing distance as the E3X-ZV.
