O5D101 IFM Photoelectric Distance Sensor | Industrial Sensors – krishna-machinery-tools-kmt

IFM O5D101 Photoelectric Distance Sensor | 40 m Range | Time-of-Flight Technology | Industrial Grade

The IFM O5D101 is a high-precision photoelectric distance sensor engineered for long-range detection up to 40 meters using time-of-flight measurement. Ideal for industrial environments, it ensures reliable performance with glossy surfaces and challenging backgrounds.

🔧 Technical Specifications:

• Brand: IFM

• Model No.: O5D101 (O5DLCPKG/US)

• Sensor Type: Photoelectric Distance Sensor

• Detecting Distance (Rated): 10 mm

• Maximum Distance Range: 40 m

• Housing Material: PBT

• Color: Orange

• Supply Voltage: 30 V DC

• Current Consumption: 30 mA

• Protection Class: IP65

• Operating Temperature: -20°C to +70°C

• Accuracy: 100%

• Application: Industrial

✅ Key Features:

• Very long range of up to 40 m using time-of-flight technology

• Reliable background suppression and color-independent detection

• Clear digital display with intuitive pushbuttons for precise switch point setting

• Capable of detecting objects at oblique angles

• Accurate detection of glossy and reflective surfaces

• Robust PBT housing for demanding industrial environments

🏭 Ideal For:

• Factory automation

• Conveyor systems

• Material handling

• Object positioning and counting in harsh conditions

Upgrade your sensing capabilities with the IFM O5D101, designed to deliver precision, durability, and versatility in every industrial application.
