NM501A IFM Inductive Sensor | Industrial Sensors – krishna-machinery-tools-kmt

IFM NM504A Inductive Sensor – Long-Range, Hazardous Area Ready

Engineered for rugged industrial environments, the IFM NM504A inductive sensor offers a long sensing distance of 20 mm, making it an ideal solution for conveyor systems and hazardous area applications. With its robust stainless steel and plastic housing, this sensor ensures dependable performance even in the most demanding settings.

🔧 Technical Specifications:

• Brand: IFM

• Model Number: NM504A

• Sensor Type: Inductive

• Output Type: PNP

• Switching Function: Normally Open (NO)

• Sensing Distance: 20 mm

• Power Supply Voltage: 10 – 30 V DC

• Current Consumption: 15 mA

• Leakage Current Load: 20 mA

• Maximum Switching Current: 30 mA

• Response Frequency: 60 Hz

• Operating Frequency: 100 Hz

• Power Rating: 10 A

• Protection Class: IP67

• Material: Stainless Steel & Plastic

• Color: Blue, Orange

• Dimensions (W x H x L): 40 x 40 x 66 mm

• Weight: 189 g

✅ Key Features:

• Designed for intrinsically safe circuits

• Long sensing range ideal for conveying systems

• Durable housing suitable for harsh industrial conditions

• Five selectable sensing face positions for installation flexibility

• Reliable operation in hazardous areas

Model Code: NM501AIMC2035-N/US/2G/1D
