IFM NG5011 Inductive Sensor – Compact, Intrinsically Safe & Built for Harsh Industrial Use

The IFM NG5011 inductive sensor offers precise and reliable detection in industrial automation applications, especially where space is limited and safety is critical. With its intrinsically safe NAMUR design and durable stainless steel housing, this sensor is built to perform in demanding environments.

Key Features:

• Sensing Distance: 5 mm

• Switching Function: Normally Open (NO)

• Output Type: PNP

• Model: NG5011 (IGA2005-N/10M/1D/1G/2G)

• Power Supply Voltage: 10 – 30 V DC

• Operating Frequency: 60 Hz

• Response Frequency: 50 Hz

• Maximum Switching Current: 35 mA

• Current Consumption: 10 mA

• Leakage Current Load: 20 mA

• Power Rating: 10 A

Rugged & Compact Design:

• Dimensions: M18 x 1 / Length = 33 mm

• Body Material: Stainless Steel with Plastic Components

• Color: Silver

• Weight: 466.5 g

• Protection Rating: IP67 – Dust-tight and water-resistant

Special Features:

• NAMUR Sensor – Designed for connection to intrinsically safe circuits

• Explosion Protection: Suitable for hazardous area applications

• Short Housing Design: Ideal for tight-space installations

• Wide Temperature Range: Reliable performance in extreme conditions

• Robust Construction: Built for long-term use in harsh industrial environments

Applications:
Ideal for hazardous area monitoring, space-constrained machinery setups, and rugged automation systems requiring high durability and precision.
