IFM NF5001 Inductive Sensor – High-Speed, Compact & Intrinsically Safe

The IFM NF5001 inductive sensor is engineered for precise object detection in industrial environments, including hazardous areas. With a compact form factor, robust protection, and NAMUR certification, this sensor delivers reliable performance even in space-constrained and harsh conditions.

Key Features:

• Sensing Distance: 15 mm

• Switching Function: Normally Open (NO)

• Output Type: PNP

• Model: NF5001 (IF-2002-N/1D/1G)

• Voltage: 10 – 30 V DC

• Current Consumption: 5 mA

• Leakage Current Load: 20 mA

• Maximum Switching Current: 30 mA

• Power Rating: 10 A

• Response Frequency: 50 Hz

• Operating Frequency: 60 Hz

Compact & Durable Design:

• Dimensions: M12 x 1 / Length = 30 mm

• Body Material: PBT Plastic

• Color: Orange

• Weight: 126.45 g

• Protection Rating: IP67 – Dust-tight and water-resistant

Advanced Features:

• NAMUR Certified Sensor – Safe for connection to intrinsically safe circuits

• Explosion Protection: Designed for use in hazardous areas

• Very High Switching Frequency: Enables fast and accurate detection

• Short Housing: Ideal for space-restricted industrial applications

• Industrial Durability: Built to perform in challenging environments

Applications:
Perfect for hazardous zones, high-speed automation systems, compact machinery layouts, and harsh industrial settings requiring safety and precision.
