NA0PA60T-31C Fuji PLC | Programmable Logic Controller – krishna-machinery-tools-kmt

Mounting Type DIN Rail Program memory 16K Steps Output Type Analog Operating ambient temperature 0 .... 55 C Operation Ambient Temperature -20 .....75 C Rated Input Voltage 24 V Brand Fuji Display Type LCD Usage/Application Industrial Number of Inputs 14 Digits Product type PLC Weight 1.5 kg Color Black \Rated input voltage Voltage tolerance Rated frequency Dropout tolerance AC waveform distortion factor Ripple factor tolerance Leakage current Inrush current Power consumption Rated output voltage Output current Insulation method Dielectric strength Insulation resistance No. of occupied slots Alarm output Multiple power supply Weight Specifications 100 to 240 V AC 85 to 264 V AC 50/60 Hz 20ms or less (Rated voltage, rated load) 5% or less — 0.25mA or less 20 Ao-p or less (at 100 V AC) 40 Ao-p or less (at 240 V AC) (ambient temperature = 25?C not repeated) 1 ms or less 220 VA or less 24 V DC (23.9 to 26.1 V DC) 0 to 2.92 A Transducer 2300 V AC, 1 minute Between power input terminal and ground 10 M? or more with 500 V DC megger 2 slots Relay NC contact output (Monitoring of output voltage: 24 V DC, 0.3 A or less) Compatible (Up to 2 units mountable on the base board *1) Approx. 600 g NP1S-62S 110 V AC 85 to 140 V AC — 10ms or less (Rated voltage, rated load) — Three-phase full-wave rectification 5% or less 20 Ao-p or less (at 110 V DC) (ambient temperature = 25?C not repeated) 1 ms or less 90 W or less 1950 V AC, 1 minute Between power input terminal and
