IG5004 IFM Inductive Sensor | krishna-machinery-tools
Sensing Distance 5 mm Usage For Industrial Output PNP Body Material Stainless Steel Voltage 30 V Current 15mA Switching Function Normally open (NO) Brand IFM Sensor Type Inductive Sensor Model Name/Number IG5004 Product Type Sensor Material Plastic Usage/Application Industrial Dimension M18 x 1 / L = 80 Response frequency 200 Power supply voltage 250 V Protection circuits IP 67 Operating Frequency 200 Dimension (W x H x L) M18 x 1 / L = 80 Maximum Switching Current 30 mA Weight 120 Product characteristics Electrical design PNP Output function normally open Sensing range [mm] 5 Housing threaded type Dimensions [mm] M18 x 1 / L = 80 Electrical data Operating voltage [V] 10...55 DC Current consumption [mA] 15; (24 V) Protection class II Reverse polarity protection no Outputs Electrical design PNP Output function normally open Max. voltage drop switching output DC [V] 1 Permanent current rating of switching output DC [mA] 400 Switching frequency DC [Hz] 200 Short-circuit protection no Overload protection no Detection zone Sensing range [mm] 5 Real sensing range Sr [mm] 5 ± 10 % Operating distance [mm] 0...4.05 Accuracy / deviations Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.4 / alum
Details
This product is crafted with quality materials to ensure durability and performance. Designed with your convenience in mind, it seamlessly fits into your everyday life.
