HG-F13A-A-N Panasonic Micro Laser Distance Sensor | krishna-machinery-tools-kmt

Distance range 40m Brand Panasonic Ambient Temperature Operation -10 ....... +45 C Supply Current 40 mA Supply Voltage 12 - 24 V Protection Class IP67 Material PBT Color Black Working Temperature -25 ........ +70 C Usage/Application Industrial Accuracy 100 % Max Pressure 20 Bar Pressure Bar 30 Bar Model No. HG-F13A-A-N Product Type Sensor Product Sensor Type Micro Laser Distance Sensor Control output NPN Ambient temperature -10 ....... +45 C Product Number HG-F13A-A-N Part Number HG-F13A-A-N Products Name Laser Distance Sensor Product details NPN output type Measurable range 250 to 3,000 mm 9.843 in to 118.110 in Displayable range 200 to 3,300 mm 7.874 in to 129.921 in (Note 2):When an object is detected, the range of numerical values that appear on the digital display is regarded as the displayable distance. When zero setting is performed, the displayable distance varies depending on the zero setting distance. Repeatability 10 mm 0.394 in or less (target object: sheet of white non-glossy paper measuring 200 × 200 mm 7.874 × 7.874 in) Hysteresis 30 mm 1.181 in (default setting) Possible to vary up to 1 mm 0.039 in minimum in the PRO mode (Note 3) (Note3):Changing the hysteresis may result in unstable sensing. After making a change, perform operation check using actual equipment.
