H3DKZ-A1 Omron On-Delay Timer | krishna-machinery-tools-kmt Industrial Automation
Type Analog Brand Omron Usage/Application Industrial Rated Voltage 24 to 240 VAC Model Name/Number H3DKZ-A1 Rated Current 0.25 mA Automation Grade Semi-Automatic Material PBT Color White Frequency 80 Hz Phase 2 Phase Weight 120 g Current 0.25 A Accuracy 100 % Pressure 800 Bar Range 0.1 to 1.2 s Voltage 24 .... 240 VAC Insulation Resistance Yes I Deal In New Only Approx Weight 110 g Power supply voltage *1 24 to 240 VAC/DC, 50/60 Hz *2 12 VDC *2 Allowable voltage fluctuation range 24 to 240 VAC/DC: 85% to 110% of rated voltage 12 VDC: 90% to 110% of rated voltage Power reset Minimum power-OFF time: 0.1 s Reset voltage 10% of rated voltage *3 Power consumption *4 H3DKZ-A1 At 240 VAC: 6.6 VA max. H3DKZ-A2 At 240 VAC: 4.5 VA max. Control output Contact output, 5 A at 250 VAC with resistive load (cos? = 1), 5 A at 30 VDC with resistive load Ambient operating temperature -20 to 55°C (with no icing) Storage temperature -40 to 70°C (with no icing) Ambient operating humidity 25% to 85%
