FS-N18N Keyence Optical Fiber Amplifier | krishna-machinery-tools-kmt
Voltage 10-30V Type Optical Fiber Amplifier Light Source Red LED Interface IO- Model Number FS-N18N Switching Frequency 50 Hz Switching Output PNP Housing M8 Housing Material Stainless Steel Degree of Protection IP54 Operating Temperature -40 to 125 Deg C No Load Supply Current 10 amp Supply voltage UB 10 - 24 V Model No. FS-N18N Color Black Weight 75 g Light source Red, 4-element LED APC ON/OFF switchable (Factory setting: OFF) Response time 50 µs (HIGH SPEED) /250 µs (FINE) /500 µs (TURBO) /1 ms (SUPER) /4 ms (ULTRA) /16 ms (MEGA) Number of interference prevention units 0 for HIGH SPEED; 4 for FINE; 8 for TURBO/SUPER/ULTRA/MEGA (When set to double, the number of interference-prevention units will be doubled.) Unit expansion Up to 16 units can be connected total (two output type is treated as two units) Rating Power voltage 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less Current Consumption Normal: 900 mW or less (36 mA max. at 24 V, 48 mA max. at 12 V)*1 Eco on mode: 800 mW or less (32 mA max. at 24 V, 39 mA max. at 12 V)*1 Eco Full mode: 470 mW or less (19 mA max. at 24 V, 23 mA max. at 12 V)
Details
This product is crafted with quality materials to ensure durability and performance. Designed with your convenience in mind, it seamlessly fits into your everyday life.
