EX-11P Panasonic Photoelectric Sensor | Compact & Reliable – krishna-machinery-tools-kmt

Material PBT Accuracy 100/% Active Area 8 mm Operating temperature *25 .... 70 C Model No. EX-11P Brand Panasonic Product Type Photoelectric Sensor Output 30 V Weight 55 g Voltage 1000 V AC Specifications table for model EX-11A-PN Item Performance characteristics CE Marking Directive Compliance ?EMC Directive ? EN 60947-5-2 ?RoHS Directive ?ISO 13849-1 (Category 1, PLc) (Note) (Note) : Conformed from December 2021 production. Sensing Range 150 mm 5.906 in Min. Sensing Object ø1 mm ø0.039 in opaque object (Completely beam interrupted object) (Setting distance between emitter and receiver: 150 mm 5.906 in) Hysteresis - Repeatability (Perpendicular to Sensing Axis) 0.05 mm 0.002 in or less Supply Voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less Current Consumption Emitter: 10 mA or less Receiver: 10 mA or less Output PNP open-collector transistor - Maximum source current: 50 mA - Applied voltage: 30 V DC or less (between output and +V) - Residual voltage: 2 V or less (at 50 mA source current), 1 V or less (at 16 mA source current) Output: Utilization Category DC-12 or DC-13
