E3S-AD633 Omron Photoelectric Sensor | Original & New | krishna-machinery-tools-kmt
Material PBT Model No. E3S-AD633 Brand Omron Product Type Sensor Sensor Type Photoelectric Sensor Color Black Sensing method Diffuse-reflective Sensing distance 100 mm Accuracy 100 % Application Industrial Control output NPN Shape Square type Sensing method Diffuse-reflective Sensing distance White paper 100 x 100 mm: 100 mm Differential distance 20% max. of sensing distance Light source Infrared LED (850 nm) Power supply voltage 10 to 30 VDC ripple (p-p) 10% included Current consumption 35 mA max. Control output NPN open collector 30 VDC max. 100 mA max. Residual voltage: 1 V max. Operation mode Light-ON/Dark-ON selectable Protective circuit Output short-circuit protection, Power supply reverse polarity protection Response time Operate or reset: 0.5 ms max. Sensitivity setting 2-turn endless adjustment (with indicator) Ambient illuminance Incandescent lamp: 5,000 lx max. Sunlight: 10,000 lx max. Ambient temperature range (Operating) -25 to 55 ? (with no freezing or condensation)
Details
This product is crafted with quality materials to ensure durability and performance. Designed with your convenience in mind, it seamlessly fits into your everyday life.
Shipping & Returns
We strive to process and ship all orders in a timely manner, working diligently to ensure that your items are on their way to you as soon as possible.
We are committed to ensuring a positive shopping experience for all our customers. If for any reason you wish to return an item, we invite you to reach out to our team for assistance, and we will evaluate every return request with care and consideration.
