DVP06XA-S Delta PLC | Compact Programmable Logic Controller | krishna-machinery-tools-kmt

Mounting Type Panel Mount Communication Interface RS 485 Brand Delta Usage/Application Industrial Number of Inputs 14 Digits Degree of Protection IP66 Product Type PLC Color White Weight 859 g Accracy 100 % Voltage 10 - 30 V Thank you for choosing DELTA DVP Series PLC. The DVP06XA-S allows the connection of four analog inputs and 2 groups 12 bits digital outputs (voltage/current). The PLC converts the input into a 12-bit digital signal and the output into a 2 points analog signal, which then are manipulated by using TO and FROM commands in the ladder logic program. There are 49 Controlled Registers (CR, each register has 16-bit) in each module. The DVP06XA-S series can read/write the data by using commands FROM / TO via DVP-PLC SS/SA/SX MPU program. z Software version of DVP06XA-S analog input/output mixed module can be updated via RS-485. Power supply and main processing units are sold separately. z Users can select input from voltage or current via wiring. Voltage input range is ±10V DC (resolution is 5 mV) and current is ±20mA (resolution is 20 ?A). z Users can select output from voltage or current via wiring. Voltage output range is 0V ~ +10V DC (resolution is 2.5 mV) and current is 0mA ~ 20mA (resolution is 5 ?A).
