DVP06AD-S Delta PLC | Compact Analog Input/Output PLC | krishna-machinery-tools-kmt

Mounting Type Panel Mount Communication Interface RS 485 Output Type Analog Brand Delta Usage/Application Industrial Number of Inputs 14 Digits Degree of Protection IP64 Model No. DVP06AD-S Product Type PLC Range of analog input 10 V Current 20 mA Color White Weight 1.5 kg Analog input channel 6 channels/module Range of analog input ±10V ±20mA Range of digital conversion ±8,000 ±4,000 Resolution 14 bits (1LSB=1.25mV) 13 bits (1LSB=5?A) Input impedance 200K? or more 250? Overall accuracy ±0.5% when in full scale (25°C, 77°F) ±1% when in full scale in the range of 0 ~ 55°C, 32 ~ 131°F Response time 3ms × the number of channels Isolation An analog circuit is isolated from a digital circuit by an optocoupler, but the analog channels are not isolated from one other. Range of absolute input ±15V ±32mA Digital data format 13 significant bits out of 16 bits are available; in 2's complement. Average function Yes. Available for setting up in CR#2 ~ CR#7; range: K1 ~ K20. Self-diagnosis Upper and lower bound detection/channel Communication mode (RS-485) ASCII/RTU mode. Communication speed: 4,800/9,600/19,200/38,400/57,600/115,200 ASCII data format: 7-bit, even bit, 1 stop bit (7, E, 1) RTU data format: 8-bit, even bit, 1 stop bit (8, E, 1) RS-485 cannot be used when connected to PLC MPU in series. When connected to DVP-PLC MPU in series The modules are numbered from 0 to 7 automatically by their distance from MPU. Maximum 8 modules are allowed to connect to MPU and will not occupy any digital I/O points.
