DI5023 IFM Compact Evaluation Unit | Sensor Testing Tool – krishna-machinery-tools-kmt

Temperature Range -50 DegreeC to +200 DegreeC Type Speed Monitoring Sensor Dia 30mm Output PNP NO Length 92.3mm Sensing Range 10mm Application simple evaluation of rotating and linear movement with regard to underspeed; blocking Setting Range 5....3600 lmp/min Product characteristics Electrical design PNP Output function normally open Sensing range[mm] 10 Housing threaded type Dimensions[mm] M30 x 1.5 / L = 92.3 Application Application simple evaluation of rotating and linear movement with regard to underspeed; blocking Electrical data Nominal voltage DC[V] 10...36 Current consumption[mA] < 20 Protection class III Reverse polarity protection yes Outputs Total number of outputs 1 Electrical design PNP Output function normally open Max. voltage drop switching output DC[V] 2.5 Permanent current rating of switching output DC[mA] 250 Short-time current rating of switching output[mA] 250 Short-circuit proof yes Overload protection yes Detection zone Sensing range[mm] 10 Sensing range adjustable no Operating distance[mm] 0...8.1 Measuring/setting range Setting range[Imp/min] 5...3600 Measuring principle inductive Accuracy / deviations Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminium: 0.4 / copper: 0.3 Hysteresis[% of Sr]
