DBS36E-S3EK02048 SICK Incremental Encoder | Motion Control | krishna-machinery-tools-kmt
Brand Sick Material Stainless Steel Model/Type DBS36E-S3EK02048 Encoder Type Incremental Shaft Diameter 6 mm x 12 mm Operating Voltage Range 7 V...30 V Initialization Time 3 ms Load Current Max 30 mA Pulses Per Revolution 2048 Shaft Material Stainless Steel Sick DBS36E-S3EK02048 Incremental Encoder, Sick DBS36 Incremental Encoder DBS36E-S3EK02048 Specification/Additional Details Brand : Sick Encoder Type : Incremental Shaft Diameter : 6 mm x 12 mm Model : DBS36E-S3EK02048 Operating Voltage Range : 7 V~30 V Initialization Time : < 3 ms Load Current Max. : 30 mA Pulses Per Revolution : 2,048 Shaft Material : Stainless Steel Housing Material : Aluminum Maximum Operating Speed : 8,000 U/min Measuring Step : 90 Degree / electronically/pulses Start up Torque : 0.5 Ncm (+20 DegreeC) Mechanical Interface : Solid Shaft, Face Mount Flange Maximum Output Frequency : 300 kHz Operating Torque : 0.4 Ncm (+20 DegreeC)
Details
This product is crafted with quality materials to ensure durability and performance. Designed with your convenience in mind, it seamlessly fits into your everyday life.
Shipping & Returns
We strive to process and ship all orders in a timely manner, working diligently to ensure that your items are on their way to you as soon as possible.
We are committed to ensuring a positive shopping experience for all our customers. If for any reason you wish to return an item, we invite you to reach out to our team for assistance, and we will evaluate every return request with care and consideration.
Shop The Full Collection
