CX-481 Panasonic Photoelectric Sensor | krishna-machinery-tools

Product Number CX-481 Part Number CX-481 Products Name Compact Photoelectric Sensor Product details Retroreflective(For transparent object sensing) The price of the product Please contact our office Applicable regulations and certifications CE Marking (EMC Directive, RoHS Directive), UKCA Marking (EMC Regulations, RoHS Regulations), UL Recognition Certification Sensing range 50 to 500 mm 1.969 to 19.685 in (Note) The sensing range and the sensing object of the retroreflective type sensor are specifi ed for the RF-230 reflector. The sensing range represents the actual sensing range of the sensor. Sensing object Ø50 mm Ø1.969 in or more transparent,translucent or opaque object (Note) The sensing range and the sensing object of the retroreflective type sensor are specifi ed for the RF-230 reflector. The sensing range represents the actual sensing range of the sensor. (Note) Make sure to confirm detection with an actual sensor before use. Hysteresis - Repeatability(perpendicular to sensing axis) 0.5 mm 0.020 in or less Supply voltage 12 to 24 V DC plus or minus 10 % Ripple P-P 10 % or less Current consumption 10 mA or less Output NPN open-collector transistor - Maximum sink current: 100 mA - Applied voltage: 30 V DC or less (between output and 0 V) - Residual voltage: 2 V or less (at 100 mA sink current), 1 V or less (at 16 mA sink current) Output:Output operation Switchable either Light-ON or Dark-ON Output:Short-circuit protection Incorporated Response time 1 ms or less Operation indicator Orange LED(lights up when the output is ON) (incorporated on the receiver for thru-beam type) Stability indicator Green LED(lights up under stable light received condition or stable dark condition) (incorporated on the receiver for thru-beam type)
