CJ1W Series OMRON PLC | Industrial Automation Controllers – krishna-machinery-tools-kmt

Omron CJ1W-MD231 Digital I/O Module | 14 Inputs | 12–24V DC Panel Mount

Boost the flexibility and efficiency of your automation systems with the Omron CJ1W-MD231, a high-performance Digital I/O Module designed for industrial-grade control systems. With 14 digital inputs, reliable panel mount configuration, and compatibility with 12–24V DC systems, this module is ideal for demanding automation environments.

🔧 Product Features:

• Brand: Omron

• Model Number: CJ1W-MD231

• Product Type: Digital I/O Module (Series Type)

• Mounting Type: Panel Mount

• Output Type: Digital

• Rated Input Voltage Range: 12 to 24 VDC

• Color: Silver

• Weight: 90 g

• Usage/Application: Industrial Automation

⚙️ Input Section (CN2):

• Number of Inputs: 14 Digital

• Rated Input Voltage: 24 VDC

• Operating Input Voltage Range: 20.4 to 26.4 VDC

• Input Current: 7 mA (typical at 24 VDC)

• Input Impedance: 3.3 kΩ

• ON Response Time: 0.1 ms max

• OFF Voltage / OFF Current: 5 VDC max / 1 mA max

• ON Voltage / ON Current: 14.4 VDC min / 3 mA min

• Residual Voltage: 1.5 V max

• ON Response Time (Configurable): Up to 8.0 ms (0–32 ms range via setup)

⚡ Output Section (CN1):

• Rated Voltage: 12 to 24 VDC

• Operating Load Voltage Range: 10.2 to 26.4 VDC

• Maximum Load Current: 0.5 A per point / 2.0 A per unit

• Maximum Inrush Current: 4.0 A per point (max 10 ms)

• Leakage Current: 0.1 mA max

✅ Why Choose the CJ1W-MD231?

• Compact and lightweight for panel integration

• High-speed switching with configurable response times

• Stable performance across industrial voltage ranges

• Ideal for controlling digital devices in factory automation

Upgrade your control panels with the Omron CJ1W-MD231 for seamless integration, precision input handling, and robust reliability in industrial environments.
