Baumer UNAM-18I6903-S14 Ultrasonic Distance Measuring Sensor | High-Precision Industrial Sensor | krishna-machinery-tools-kmtasuring Sensor

Baumer Ultrasonic Sensor – 40 mm Sensing Distance | High-Precision Industrial Detection

Designed for precision in demanding industrial environments, the Baumer Ultrasonic Sensor offers accurate object detection with quick response time, compact build, and robust housing. Ideal for distance measurement and positioning tasks, this sensor supports high-resolution sensing with exceptional repeat accuracy.

🔧 Technical Specifications:

• Brand: Baumer

• Sensor Type: Ultrasonic

• Sensing Distance: 40 mm

• Scanning Range (Sd): 100 – 1000 mm

• Scanning Range Close Limit (Sdc): 100 – 1000 mm

• Scanning Range Far Limit (Sde): 100 – 1000 mm

• Supply Voltage: 12 – 30 V DC

• Supply Current: 35 mA

• Frequency: 3 kHz | Sonic Frequency: 240 kHz

• Repeat Accuracy: 0.5 mm

• Resolution: < 0.3 mm

• Response Time (ton): < 80 ms

• Release Time (toff): < 80 ms

• Temperature Drift: < 2% of Sde (> 50 mm)

• Housing Material: Brass, nickel-plated

• Sensor Body Material: PBT

• Color: Black

• Operating Temperature: -45°C to +70°C

• Accuracy: 100%

• Adjustment: Teach-in

• Alignment Aid: Flashing target indication

• Light Indicator: Yellow LED / Red LED

✅ Key Features:

• High precision with <0.3 mm resolution

• Fast response time under 80 ms

• Robust brass housing with nickel plating for industrial durability

• Wide operating temperature range (-45°C to +70°C)

• Built-in Teach-in function for quick and easy calibration

• Visual alignment and status with dual-color LED indicators

• Excellent repeatability (0.5 mm) for consistent performance

The Baumer 40 mm Ultrasonic Sensor is engineered for applications requiring accuracy, reliability, and speed. From packaging lines to robotics and factory automation, this sensor ensures optimal performance with every use.
